Blue Sea Power Distribution Box 8086
Blue Sea Power Distribution Box
Power Distribution Box; AC/DC Combination Circuit Breaker Panel; 120 Volts AC/ 12 Volts DC; Traditional Metal; 3 Sources AC And 12 Positions AC And 19 Positions DC; Black; 19-1/2 Inch Width x 11-1/2 Inch Height x 3 Inch Depth; With Basic DC Panel Label Set - 30 Labels/ Basic AC Panel Label Set - 30 Labels/ 6 A-Series White Toggle Circuit Breaker - Single Pole 15 Amps (AC Branch)/ 2 A-Series White Toggle Circuit Breaker - Double Pole 30 Amps (AC Main)/ A-Series White Toggle Circuit Breaker - Double Pole 50 Amps (AC Main)/ AC Ammeter - 0 To 50 Amps With Coil/ AC Voltmeter - 0 To 150 Volts AC/ A-Series White Toggle Circuit Breaker - Double Pole 30 Amps (AC Transfer)/ 13 A-Series White Toggle Circuit Breaker - Single Pole 15 Amps (DC Branch)/ Circuit Breaker CA1 100 Amps Red IP (DC Main)/ DC Analog Voltmeter - 8 To 16 Volts DC/ DC Analog Ammeter - 0 To 100 Amps With Shunt
MPN: 8086
Features
- All AC And DC Buses Installed And Fully Pre-Wired
- Label Backlighting Pre-Installed
- ON - Indicating LEDs Installed In All Circuit Positions
- Limited 90 Day Warranty
| Specifications of Blue Sea Power Distribution Box 8086 | |
| Color | Black |
| GFCI/ Overload Protection | Yes |
| Height (IN) | 11-1/2 Inch |
| Length (IN) | 19-1/2 Inch |
| Material | Aluminum |
| Number Of Connections | 12 |
| Power Rating | 15 Amp/ 30 Amp/ 50 Amp/ 100 Amp |
| Receptacle Type | No Receptacle |
| UL Listed | No |
| Voltage Rating | 120 Volt AC/ 12 Volt DC |
| Width (IN) | 3 Inch |
| With Flip Cover | No |
